The 74HC368 is a hex inverting buffer and line driver IC from Texas Instruments, designed for high-speed digital logic applications. It features six inverting buffers with high current drive capability, making it suitable for driving TTL and CMOS logic levels. Housed in a compact SOIC-16 SMD package, it is ideal for space-constrained PCB designs.

Specifications:

• IC Type: Hex Inverting Buffer/Line Driver
• Manufacturer: Texas Instruments
• Package Type: SOIC-16 SMD
• Package Size: 16 Pins
• Supply Voltage Range: 2 V to 6 V
• Input Voltage Range: 0 V to Vcc
• Output Drive Current: 25 mA (typical)
• Propagation Delay: 7 ns (typical at 5 V)
• Operating Temperature Range: -40°C to 85°C

Pin Configuration:

1. 1A: Input for buffer 1
2. 1Y: Output for buffer 1
3. 2A: Input for buffer 2
4. 2Y: Output for buffer 2
5. 3A: Input for buffer 3
6. 3Y: Output for buffer 3
7. GND: Ground
8. 4A: Input for buffer 4
9. 4Y: Output for buffer 4
10. 5A: Input for buffer 5
11. 5Y: Output for buffer 5
12. 6A: Input for buffer 6
13. 6Y: Output for buffer 6
14. Vcc: Supply Voltage
15. NC: No Connection
16. NC: No Connection

Features:

• Six independent inverting buffers
• High current drive capability
• High-speed operation
• TTL and CMOS compatible
• Compact SOIC-16 SMD package

Applications:

• Digital logic interfacing
• Signal buffering
• Line driving
• Data communication
• High-speed data processing

Package Includes:

• 1 x 74HC368 Hex Inverting Buffer Line Driver IC (SOIC-16 SMD Package)

Note: Product images are for illustrative purposes only and may differ from the actual product.
